Socket compatibility
Intel LGA2066, LGA2011-0 & LGA2011-3 (Square ILM), LGA1156, LGA1155, LGA1151, LGA1150

AMD AM2, AM2+, AM3, AM3+, FM1, FM2, FM2+ (backplate required), AM4 (included since 2019, older coolers require NM-AM4-UxS)

Height (without fan)
125 mm
Width (without fan)
95 mm
Depth (without fan)
68 mm
Weight (without fan)
524 g
Height (with fan)
125 mm
Width (with fan)
95 mm
Depth (with fan)
95 mm
Weight (with fan)
618 g
Material
Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
Max. TDP
see CPU compatibility list
Fan compatibility
92x92x25
Scope of delivery

NF-A9 PWM premium fan
Low-Noise Adaptor (L.N.A.)
NT-H1 high-grade thermal compound
SecuFirm2™ Mounting Kit
Fan-clips for second NF-A9
Noctua Metal Case-Badge

Warranty
6 Years
FAN Specification
Model
Noctua NF-A9 PWM
Bearing
SSO2
Max. rotational speed (+/- 10%)
2000 RPM
Max. rotational speed with L.N.A. (+/- 10%)
1550 RPM
Min. rotational speed (PWM, +/-20%)
400 RPM
Max. airflow
78,9 m³/h
Max. airflow with L.N.A.
62,6 m³/h
Max. acoustical noise
22,8 dB(A)
Max. acoustical noise with L.N.A.
16,3 dB(A)
Input power
1,2 W
Voltage range
12 V
MTTF
> 150.000 h
