Deskripsi Casing PC Fractal Design Define S2 TG Gunmetal

3.5"/2.5" Universal drive brackets
3

Dedicated 2.5" drive brackets
2

Expansion slots
7 + 2 vertical

Motherboard compatibility
EATX (up to 285 mm wide), ATX, mATX, ITX
Power supply type

ATX
Front ports
1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0,
2 x USB 2.0, Audio I/O
Total fan mounts
9

Front fan
3 x 120/140 mm, (2 x Dynamic X2 GP-14 included)
Top fan
3 x 120/140 mm
Rear fan
1 x 120/140 mm (1 x Dynamic X2 GP-14 included)

Bottom fan
2 x 120/140 mm
Dust filters
Bottom fan + PSU
Front fans
Top panel
Front radiator
120/240/360 mm
140/280 mm

Top radiator
- 120/240/360 mm
- 140/280/420 mm (max 35 mm motherboard component height)
Rear radiator
120 mm
Bottom radiator
120/240 mm
140/280 mm
PSU max length
300 mm
GPU max length
Max 440 mm with front fan mounted
CPU cooler max height
185 mm
Cable routing space
23 mm
Cable routing grommets
Yes
Fixed velcro straps
Yes
Tool-less push-to-lock
Both side panels
Captive thumbscrews
HDD brackets, SSD brackets
Left side panel

Black/Blackout/Gunmetal versions: Light tint tempered glass
White version: Clear tempered glass
Right side panel
Industrial sound-dampened steel

Dimensions
Case dimensions (LxWxH)
543 x 233 x 465 mm

Case dimensions w/o feet/protrusions/screws
535 x 233 x 448 mm

Net weight
11.6 kg

Package dimensions (LxWxH)
535 x 325 x 650 mm

Package weight
13.4 kg
