CHIPSET
- INTEL B760

CPU SUPPORT
- Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors
- LGA 1700

MEMORY
- 2x DDR4, Maximum Memory Capacity 64GB
- Memory Support 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC)

ONBOARD GRAPHICS
- 1x HDMI™
Support HDMI™ 1.4 with HDR, maximum resolution of 4K 30Hz*
- 1x VGA
Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz

EXPANSION SLOT
- 1x PCI-E x16 slot
- 1x PCI-E x1 slot
- PCI_E1 Gen PCIe 4.0 supports up to (From CPU)
- PCI_E2 Gen PCIe 3.0 supports up to (From Chipset)

STORAGE
- 1x M.2
- M.2_1 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
- 4x SATA 6G

LAN
- Realtek® RTL8111H Gigabit LAN

AUDIO
- Realtek® ALC897 Codec
- 7.1-Channel High Definition Audio

AUDIO
- Realtek® ALC897 Codec
- 7.1-Channel High Definition Audio

PCB DIMENSION (W × L)
- mATX
- 200mmx236.16mm
