SPESIFIKASI

P/N : CA-1X3-00M6WN-00
Series : View
Model : View 200 TG ARGB Snow
CASE TYPE : Mid Tower

Dimension (H x W x D) :
460x 210 x 395.3 mm
(18.11 x 8.27 x 15.56 inch)

PANEL : 3mm Tempered Glass x 1
MATERIAL : SPCC

COOLING SYSTEM
Front(intake) : 120 x 120 x 25 mm ARGB Lite fan (1000rpm, 22.3 dBA) x 3

Drive Bays : 2 x 3.5”, 2 x 2.5” or 1 x 3.5”, 3 x 2.5”
EXPANSION SLOTS : 7

MOTHERBOARDS :
6.7" x 6.7" (Mini ITX), 9.6" x 9.6" (Micro ATX),
12" x 9.6" (ATX)

I/O Port : USB 3.0 x 2, HD Audio x 1
PSU : Standard PS2 PSU (optional)

FAN SUPPORT
Front :
3 x 120mm, 2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm

Top :
2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm

Rear :
1 x 120mm

RADIATOR SUPPORT
Front :
1 x 360mm, 1 x 240mm, 1 x 120mm
1 x 280mm, 1 x 140mm

Top :
1 x 240mm, 1 x 120mm

Rear :
1 x 120mm

CLEARANCE
CPU cooler max height : 166mm

VGA max length :
300mm (with radiator)
330mm (without radiator)

PSU max length : 190mm (with HDD Cage)
