SPESIFIKASI:
Device Interfaces
5 x Gigabit Ethernet LAN ports, 1 x power connector
Standards
• IEEE 802.3 10BASE-T Ethernet
• IEEE 802.3u 100BASE-TX Fast Ethernet
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x Flow Control
• IEEE 802.3az Energy-Efficient Ethernet (EEE)
Advanced Features
• Green Ethernet
• 10 Gbps switching fabric
• Auto MDI/MDIX crossover for all ports
• Secure store-and-forward switching scheme
• Full/half-duplex for Ethernet/Fast Ethernet speeds
• IEEE 802.3x Flow Control
• Supports 9KB Jumbo Frame
• Supports IEEE 802.1p QoS
Data Transfer Rates
• Ethernet:
• 10 Mbps (half duplex)
• 20 Mbps (full duplex)
Fast Ethernet:
• 100 Mbps (half duplex)
• 200 Mbps (full duplex)
Gigabit Ethernet:
• 2000 Mbps (full duplex)
Transmission Method
Store-and-forward
MAC Address Table
2K
MAC Address Learning
Automatic Update
Packet Buffer
128 KB
LED Indicators
• Per port: Link/Activity
• Per device: Power
Media Interface Exchange
Auto MDI/MDIX for all ports
Dimensions
94 x 75 x 22.45 mm
Weight
75 g
Power
5 V/1 A Power Adapter
MTBF
|
