SPESIFIKASI:
Packet Buffer Size
N/A
FAN
No
Comply with RoHS 6
Yes
Energy Efficiency Ethernet EEE
Yes
Power Saving By Link Status
Yes (suggest to remove this feature)
Power Saving By Cable Length
Yes (suggest to remove this feature)
Jumbo Frame
9216 Bytes
Number of Queues
8
Store Forwarding
Yes
Dimension
140 x 67 x 26 mm
Weight
0.24 kgs
Operation Temperature
0 ~ 40 °C
Storage Temperature
- 10 ~ 65 °C
Operation Humidity
0% ~ 95% RH
Storage Humidity
0% ~ 95% RH
Maximum Power Consumption
4.31W
Standby Power Consumption
0.93W
Maximum Heat Dissipation
14.70 BTU/h
MTBF
1,402,428 hours
Power Input
5V DC
8023x Flow Control
Yes
MAC Address Table Size
4K
1000Base-T Interface
Yes
Auto MDIMDIX
Yes
Switching Capacity
16Gbps
Max Packet Forwarding Rate
|
