SPESIFIKASI :

CPU : Support Intel® Core™ Ultra Processors(Series 2) , LGA1851

Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**

• Refer to CPU support list.

** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.

Chipset

Intel® Z890 Chipset

Memory : 2 x DIMM slots, max. 96GB, DDR5

Supports up to 9600+ MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*

Dual Channel Memory Architecture

DIMM Fit

Supports Intel® Extreme Memory Profile (XMP) memory module

Supports DIMM Flex

ASUS Enhanced Memory Profile III (AEMP III)

• Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit Adjustments will be made based on the specifications of mass-produced memory products available on the market.

• Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.

Graphics : 2 x Intel® Thunderbolt™ 4 ports (USB Type-C®) support DisplayPort and Thunderbolt™

• Graphics specifications may vary between CPU types.

**In Thunderbolt4TM mode, supports up to 8K@60Hz x1 with DSC or 4K@60Hz x 2, maximum total bandwidth up to 23.8Gbps or 16Gbps/16Gbps, for resolution support please check DisplayPort 2.1 specs.

***In DP alt mode, Only one USB Type-C® port supports up to UHBR20 at a time.

**** VGA resolution support depends on processors' or graphic cards' resolution.

*****While installing the operating system, please ensure that your monitor is connected to a discrete graphics card.

Storage : Total supports 6 x M.2 slots and 4 x SATA 6Gb/s ports*

Support Intel® Core™ Ultra Processors(Series 2) *

M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)

M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)

M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 modes)**

M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 modes)**

Intel® Z890 Chipset

DIMM.2_1 slot (Key M) via ROG DIMM.2, type 2230/2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)

DIMM.2_2 slot (Key M) via ROG DIMM.2, type 2230/2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)

4 x SATA 6Gb/s ports

• Intel® Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10, M.2 slot from CPU only supports RAID 0/1/5.

**M.2_3 & M.2_4 share bandwidth with PCIEX16(G5)_2. When M.2_3 is enabled, PCIEX16(G5)_1 will run x8 & PCIEX16(G5)_2 will run x4. When M.2_3 & M.2_4 are enabled, PCIEX16(G5)_1 will run x8 & PCIEX16(G5)_2 will disabled.

Ethernet : 1 x Realtek 5Gb Ethernet

ASUS LANGuard

USB : Rear USB (Total 11 ports)

2 x Thunderbolt™ 4 ports (2 x USB Type-C®)

1 x USB 20Gbps port (1 x USB Type-C®)

4 x USB 10Gbps ports (4 x Type-A)

4 x USB 5Gbps ports (4 x Type-A)

Front USB (Total 10 ports)

1 x USB 20Gbps connector (supports USB Type-C® with up to 60W PD/QC4+)*

1 x USB 10Gbps connector (supports USB Type-C®)

2 x USB 5Gbps headers support 4 additional USB 5Gbps ports

2 x USB 2.0 headers support 4 additional USB 2.0 ports

USB Type-C® power delivery output: max. 5V/3A

*USB Type-C® power delivery output: 5/9/15/20V max. 3A, PPS:3.3–21V max. 3A

Audio : "ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*

• Impedance sense for front and rear headphone outputs

• Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking

• High quality 120 dB SNR stereo playback output and 110 dB SNR recording input

• Supports up to 32-Bit/384 kHz playback on front panel"

Audio Features

• SupremeFX Shielding Technology

• Savitech SV3H712 AMP

• Gold-plated audio jacks

• Rear optical S/PDIF out port

• Premium audio capacitors

• Audio cover

• A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

** The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device.

Special Features

Extreme OC Kit

• FlexKey button

• LN2 Mode

• ProbeIt

• ReTry button

• Safe boot button

• Start button

• Slow Mode

Extreme Engine Digi+

• SMD Capacitor

• MicroFine Alloy Choke

ASUS Q-Design

• M.2 Q-Latch

• M.2 Q-Release

• M.2 Q-Slide

• PCIe Slot Q-Release Slim (with PCIe SafeSlot)

• Q-Antenna

• Q-Code

• Q-Dashboard

• Q-Connector

• Q-DIMM

• Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])

• Q-Slot

ASUS Thermal Solution

• M.2 heatsink backplate

• M.2 heatsink

• VRM heatsink design

ASUS EZ DIY

• BIOS FlashBack™ button

• Clear CMOS button

• CPU Socket lever protector

• ProCool II

• Pre-mounted I/O shield

• SafeSlot

• SafeDIMM

Aura Sync

• Addressable Gen 2 headers

Dual BIOS

Front Panel USB 20Gbps with Quick Charge 4+ Support

• Support: up to 60W fast charging and USB Wattage Watcher*

• Output: 5/9/15/20V max. 3A, PPS:3.3–21V max. 3A

• Compatible with PD3.0 and PPS

• To support 60W, please install the power cable to the 8-pin PCIe power connector or else only 27W will be supported.

Software Features : ROG Exclusive Software

• ROG CPU-Z

• Dolby Atmos

• Internet Security (1-year full version)

ASUS Exclusive Software

Armoury Crate

• AIDA64 Extreme (1 year full version)

• Aura Creator

• Aura Sync

• Fan Xpert 4 (with AI Cooling II)

• GameFirst

• Power Saving

• HWiNFO

ASUS AI Advisor

ASUS Driver Hub

ASUS GlideX

Turbo Vcore

Adobe Creative Cloud (Free Trial)

Thunderbolt™ Share

USB Wattage Watcher

WinRAR (40 Days Free Trial)

UEFI BIOS

AI Overclocking Guide

ASUS EZ DIY

• ASUS CrashFree BIOS 3

• ASUS EZ Flash

• ASUS UEFI BIOS EZ Mode

• ASUS MyHotkey

NPU Boost

BIOS : 2 x 256 Mb Flash ROM, UEFI AMI BIOS
