SPESIFIKASI:
Camera
Image sensor : F2.2@1/3" Progressive Scan CMOS
Shutter Speed : Self-adaptive shutter
Lens : 4mm, view angle: 88°(Diagonal), 75° (Horizontal), 41°(Vertical)
Lens Mount : M12
Day & Night : IR-cut filter with auto-switching
DNR : 3D DNR
WDR : Digital WDR
Compression
Video Compression H.265 / H.264
Video Bit Rate Quad HD; Full HD; HD; Standard. Adaptive bit rate.
Max. Resolution 2560 × 1440
Frame Rate Max. 20 fps; Self-Adaptive during network transmission
Network
Smart Alarm Motion detection
Wi-Fi Pairing AP pairing
Protocol EZVIZ cloud proprietary protocol
Interface Protocol EZVIZ cloud proprietary protocol
Interface
Storage Micro SD card slot (Max. 256G)
Power Micro USB
Wired Network RJ45 × 1 (10M/100M self-adaptive Ethernet port)
Wi-Fi
Standard IEEE802.11b, 802.11g, 802.11n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20MHz
Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate 11b: 11Mbps, 11g :54Mbps, 11n :72Mbps
General
Operating Conditions -10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing)
Power Supply DC 5V/2A
Power Consumption Max. 5W
IR Range Max. 10 m (32.81 ft)
Dimensions 88 × 88.2 × 119 mm (3.46 × 3.47 × 4.69 inch)
Packaging Dimensions 103 × 103 × 186 mm (4.06 × 4.06 × 7.30 inch)
Bare Weight 252g (8.89 oz)
In the box:
- C6N Camera
- Base
- Screw Kit
- Power Cable 3m (9.8 ft.)
- Drill Template
- Power Adapter
- Quick Start Guide
- Regulatory Information
Certifications:
FCC / UL / CE / WEEE / REACH / ROHS
|
