SPESIFIKASI:
Model
CS-H6c-R105-1J4WF
Camera
Resolution : 4MP /2K+ Resolution
Image sensor : F1.6@1/3" Progressive Scan CMOS
Shutter Speed : Self-adaptive shutter
Lens : 4mm, view angle: 90°(Diagonal), 80° (Horizontal), 43°(Vertical)
Lens Mount : M12
Day & Night : IR-cut filter with auto-switching
DNR : 3D DNR
WDR : Digital WDR
Compression
Video Compression : H.264/H.265
Video Bit Rate : Adaptive bit rate.
Max. Resolution : 2560 × 1440
Frame Rate : Max:30fps; Self-Adaptive during network transmission
Network
Smart Alarm : Motion Detection, Human Shape Detection, Loud Noise Detection, Patrol Mode Detection
Wi-Fi Pairing : AP paring
Protocol : EZVIZ cloud proprietary protocol
Interface Protocol : EZVIZ cloud proprietary protocol
Interface
Storage : Micro SD card slot (Max. 512G)
Power : TYPE-C
Wired Network : RJ45 X 1 (10M/100M self-adaptive Ethernet port)
Wi-Fi
Standard : IEEE802.11a, 802.11b, 802.11g, 802.11n,
Frequency Range : 2.4G: 2400~2483.5MHz 5G: 5150MHz-5250MHz
Channel Bandwidth : Supports 20MHz
Security : WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate : 11b 11Mbps, 11g 54Mbps, 11nHT20 MCS7, 11a 54Mbps, 11nHT20 MCS7
Output Power(EIRP) : 19 dBm
Antenna Gain : 1.9 dBi
General
Operating Conditions : -10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing)
Power Supply : DC 5V/2A
Power Consumption : 8W max
IR Range MAX. : 10 meters(32.81ft)
Dimensions : 88mm x 88.2 mm x 119mm (3.46” x 3.47” x 4.69”)
Packaging Dimensions : 103mm x 103mm x 168mm (4.06” x 4.06” x 6.61”)
Bare Weight : 252g / 8.9oz
In the box
- Camera
- Power Adapter
- Power Cable
- Drill Template
- Mounting Plate
- EZVIZ Screw Kit
- Regulatory Information
- Quick Start Guide
Certifications
CE / UL / WEEE / REACH / RoHS / UKCA
|
