| Printer |
| Maximum Printing Resolution |
9600 (horizontal)*1 x 2400 (vertical) dpi |
| Print Head / Ink |
Type: |
Individual Ink Tank |
| Number of Nozzles: |
Total 5,120 nozzles |
| Ink Droplet Size: |
1pl |
| Ink Tank: |
PGI-750 (Pigment Black), CLI-751 (Cyan / Magenta / Yellow / Black)
[Optional: PGI-755 XXL (Pigment Black), PGI-750XL (Pigment Black),
CLI-751XL (Cyan / Magenta / Yellow / Black)] |
Print Speed*2
Based on ISO / IEC 24734.
Click here for summary report
Click here for Document Print and Copy Speed Measurement Conditions |
Document: Col |
ESAT / Simplex |
approx. 10.4ipm |
| Document: B / W |
ESAT / Simplex |
approx. 14.5ipm |
| Photo (11 x 14" image) |
PP-201 |
approx. 120secs. |
| Photo (4 x 6") |
PP-201 / Borderless |
approx. 36secs. |
| Printable Width |
Up to 322.2mm (12.7inch), Borderless: Up to 329mm (13inch) |
| Printable Area |
Borderless Printing*3 |
Top / Bottom / Right / Left margin: each 0mm (Supported Paper Size: A3+, A3, A4, LTR, LDR, 4 x 6", 5 x 7", 8 x 10", 10 x 12") |
| Bordered Printing |
Top margin: 3mm, Bottom margin: 5mm,
Left / Right margin: each 3.4mm (LTR / LGL: Left: 6.4mm, Right: 6.3mm) |
| Recommended Printing Area |
Top margin: 40.7mm / Bottom margin: 37.4mm |
| Paper Size |
A3+, A3, A4, A5, B4, B5, LTR, LGL, LDR, 4 x 6", 5 x 7", 8 x 10", 10 x 12", Envelopes (DL, COM10), Custum size (width 55mm - 329mm, length 91mm - 676mm) |
Paper Handling (Rear Tray)
(Maximum Number) |
Plain Paper |
A3, A4, A5, B4, B5, LTR, LGL, LDR=150 |
| High Resolution Paper (HR-101N) |
A3+=20, A3=50, A4=80 |
| Photo Paper Pro Platinum (PT-101) |
A3+=1, A3, A4=10, 4 x 6"=20 |
| Photo Paper Plus Glossy II (PP-201) |
A3+=1, A3, A4=10, 4 x 6"=20 |
| Photo Paper Pro Luster (LU-101) |
A3+=1, A3, A4=10 |
| Photo Paper Plus Semi-Gloss (SG-201) |
A3+ =1, A3, A4, 8 x 10"=10, 4 x 6"=20 |
| Glossy Photo Paper "Everyday Use" (GP-601) |
A4=10, 4 x 6"=20 |
| Matte Photo Paper (MP-101) |
A3, A4=10, 4 x 6"=20 |
| Envelope |
European DL / US Com. #10=10 |
| Paper Weight |
Front Tray |
Plain Paper: 64-105 g/m2, Canon specialty paper: max paper weight: approx. 300 g/m2 (Photo Paper Pro Platinum PT-101) |
| Ink End Sensor |
Optical sensor + Dot count |
| Print Head Alignment |
Auto / Manual |
| Network |
|
| Protocol |
TCP/IP |
| Wired LAN |
Network Type |
IEEE802.3u （100BASE-TX） / IEEE802.3（10BASE-T） |
| Data Rate |
10M / 100Mbps (auto switchable) |
| Wireless LAN |
Network Type |
IEEE802.11n / IEEE802.11g / IEEE802.11b |
| Frequency Band |
2.4GHz |
| Channel*4 |
1-13 |
| Range |
indoor 50m (depends on the transmission speed and conditions) |
| Security |
WEP64 / 128bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES) |
| System Requirements |
| Windows: |
(Please visit www.canon-asia.com to check OS compatibility and to download the latest driver updates.) |
Windows 8 / Windows 7 / Windows XP / Windows Vista |
| Macintosh: |
Mac OS X v10.6.8 and later |
|
|
| Interface |
Wireless LAN IEEE 802.11 b / g / n, 100 Base-TX / 10 Base-T, USB 2.0 Hi-Speed |
| Apple AirPrint |
Available |
| Google Cloud Print |
Available |
| PIXMA Printing Solutions |
Available |
| Operating Environment |
Temperature: 15 - 30°C; Humidity: 10 - 80% RH (no dew condensation) |
| Storage Environment |
Temperature: 0 - 40°C; Humidity: 5 - 95%RH (no dew condensation) |
| Acoustic Noise (PC Print) |
Photo (4 x 6") *5 |
approx. 44.0dB(A) |
| Power |
AC 100-240V; 50 / 60Hz |
| Power Consumption |
Standby
Wireless LAN connection to PC |
Approx.2.0W |
| OFF: |
Approx. 0.3W |
Printing*6
Wireless LAN connection to PC |
Approx. 24W |
| Environment |
Regulation: |
RoHS (EU, China), WEEE (EU) |
| Eco-Label: |
Energy Star, EPEAT |
| Duty Cycle |
|
up to 12,000 pages / month |
| Dimension (W x D x H) |
|
approx. 584 x 310 x 159mm |
| Weight |
|
approx. 8.1kg |
