STOCK: READY STOCK

NB:
- Barang akan lebih ringan dari berat yang tertera.
* Untuk menjaga ongkos kirim dalam volume jika ada pemesanan diatas 1pcs.
- kelebihan ongkos kirim dari pelanggan akan dikirimkan kembali sesuai dengan nilai selisih.

Specification :
CPU
Support for Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1150 package L3 cache varies with CPU

(Please refer "CPU Support List" for more information.)
Chipset

    Intel® H81 Express Chipset

Memory

    2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
    * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
    Dual channel memory architecture
    Support for DDR3 1600/1333 MHz memory modules
    Support for non-ECC memory modules
    Support for Extreme Memory Profile (XMP) memory modules

(Please refer "Memory Support List" for more information.)
Onboard Graphics    Integrated Graphics Processor - Intel® HD Graphics support:

    1 x D-Sub port, supporting a maximum resolution of 1920x1200
    Maximum shared memory of 1 GB

Audio

    Realtek® ALC887 codec
    High Definition Audio
    2/4/5.1/7.1-channel
    * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.

LAN

    Realtek® GbE LAN chip (10/100/1000 Mbit)

Expansion Slots

    1 x PCI Express x16 slot, running at x16
    2 x PCI Express x1 slots
    (The PCI Express slots conform to PCI Express 2.0 standard.)

Storage Interface    Chipset:

    2 x SATA 6Gb/s connectors (SATA3 0/1) supporting up to 2 SATA 6Gb/s devices
    2 x SATA 3Gb/s connectors (SATA2 2/3) supporting up to 2 SATA 3Gb/s devices

USB    Chipset:

    Up to 2 USB 3.0/2.0 ports on the back panel
    Up to 6 USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

Internal I/O Connectors

    1 x 24-pin ATX main power connector
    1 x 4-pin ATX 12V power connector
    2 x SATA 6Gb/s connectors
    2 x SATA 3Gb/s connectors
    1 x CPU fan header
    1 x system fan header
    1 x front panel header
    1 x front panel audio header
    2 x USB 2.0/1.1 headers
    1 x Clear CMOS jumper

Back Panel Connectors

    1 x PS/2 mouse port
    1 x PS/2 Keyboard port
    1 x parallel port
    1 x serial port
    1 x D-Sub port
    2 x USB 3.0/2.0 ports
    2 x USB 2.0/1.1 ports
    1 x RJ-45 port
    3 x audio jacks (Line In, Line Out, Mic In)

I/O Controller

    iTE® I/O Controller Chip

H/W Monitoring

    System voltage detection
    CPU/System temperature detection
    CPU/System fan speed detection
    CPU/System overheating warning
    CPU/System fan fail warning
    CPU/System fan speed control
    * Whether the fan speed control function is supported will depend on the cooler you install.

BIOS

    2 x 64 Mbit flash
    Use of licensed AMI EFI BIOS
    Support for DualBIOS™
    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features

    Support for Q-Flash
    Support for Xpress Install
    Support for APP Center
    * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications.
    @BIOS
    EasyTune
    EZ Setup
    USB Blocker
    Support for ON/OFF Charge

Bundle Software

    Norton® Internet Security (OEM version)

Operating System

    Support for Windows 10/8.1/8/7

Form Factor

    Micro ATX Form Factor; 22.6cm x 17cm

Remark

    Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
    Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.



For More Information, Please Click Here

Garansi 1 Tahun

Syarat Garansi:
- Garansi berlaku untuk kerusakan internal (kerusakan pabrik)
- Fisik tidak rusak / tidak cacat fisik
- Kondisi barang masih bagus
- Segel tidak rusak
- Baca Syarat & Ketentuan
