SPESIFIKASI:
Number of Ports Sixteen
10/100/1000 Gigabit ports
Switching Capacity
32Gbps
Data Transfer Rates Ethernet
10 Mbps (half duplex)
20 Mbps (full duplex) Fast Ethernet:
100 Mbps (half duplex)
200 Mbps (full duplex)
Network Cables 10BASE-T
UTP CAT 3, 4, 5/5e (100 m max)
EIA/TIA-586 100-ohm STP (100 m max) 100BASE-TX, 1000BASE-T
UTP CAT 5/5e (100 m max)
EIA/TIA-568 100-ohm STP (100 m max)
Media Interface Exchange
Auto MDI/MDIX adjustment for all ports
LED Indicators Per port
Link/Activity/Speed
Per device: Power
Transmission Method
Store-and-forward
MAC Address Table
8k
MAC Address Learning
Automatic update
MAC Address Filtering/ Forwarding Rates
Ethernet: 14,880 pps per port
Fast Ethernet: 148,800 pps per port
Gigabit Ethernet: 1,488,000 pps per port
RAM Buffer
2Mbits
Jumbo Frames
|
