| P/N |
CA-1K1-00M1WN-00 |
| Case Type |
Middle tower |
| Dimension (H x W x D) |
465 x 205 x 447 mm
(18.3 x 8.1 x 17.5 inch) |
| Net Weight |
6.08 kg / 13.4 lb |
| Side Panel |
Tempered Glass x1 |
| Color |
Exterior & Interior : Black |
| Material |
SPCC |
| Cooling System |
Rear (exhaust) :
120 x 120 x 25 mm fan (1000rpm, 16dBA) |
Drive Bays
-Accessible
-Hidden |
2 x 3.5’’ or 2 x 2.5’’(HDD Tray); 2 x 2.5”(HDD Bracket)
2 x 2.5" |
| Expansion Slots |
7 |
| Motherboards |
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) |
| I/O Port |
USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1 |
| PSU |
Standard PS2 PSU (optional) |
| Fan Support |
Front:
3 x 120mm, 2 x 140mm
Top:
2 x 120mm, 2 x 140mm
Rear:
1 x 120mm |
| Radiator Support |
Front:
1 x 360mm, 1 x 280mm
Top:
1 x 240mm
Rear:
1 x 120mm |
| Clearance |
CPU cooler height limitation: 160mm
VGA length limitation: 310mm
PSU length limitation: 220mm |
