| Dimension (H x W x D) |
471 x 224 x 492 mm
(18.5 x 8.8 x 19.4 inch) |
| Net Weight |
8.2 kg / 18.07 lb |
| P/N |
CA-1I3-00M1WN-00 |
| Case Type |
Mid Tower |
| Side Panel |
4mm Tempered Glass x 2 (Left & Right) |
| Color |
Exterior & Interior : Black |
| Material |
SPCC |
| Cooling System |
Rear (exhaust) :
120 x 120 x 25 mm fan (1000rpm, 16dBA) |
| Drive Bays |
-Accessible
2 x 2.5’’ ; 2 x 3.5’’ or 2 x 2.5’’
-Hidden |
| Expansion Slots |
7 |
| Motherboards |
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) |
| I/O Port |
USB 3.0 x 2, HD Audio x 1 |
| PSU |
Standard PS2 PSU (optional) |
| Fan Support |
Front:
3 x 120mm , 2 x 140mm
Top:
1 x 120mm , 1 x 140mm
Rear:
1 x 120mm
Bottom:
1x 120mm |
| Radiator Support |
Front:
1 x 360mm, 1 x 280mm
Rear:
1 x 120mm |
| Clearance |
CPU cooler height limitation: 160mm
VGA length limitation: 410mm
PSU length limitation: 220mm |
