| P/N |
CA-1I7-00F1WN-01 |
| Case Type |
Full Tower |
| Dimension (H x W x D) |
592 x 274 x 577 mm
(23.3 x 10.8 x 22.7 inch) |
| Net Weight |
19.1 kg / 42.10 lb |
| Side Panel |
5mm Tempered Glass x 4
(Left & Right & Front & Top) |
| Color |
Exterior & Interior : Black |
| Material |
SPCC |
Drive Bays
-Accessible
-Hidden |
-
2.5” x 4 or 3.5”x4 (HDD Rack)
2.5”x 6 or 3.5” x 3 |
| Cooling System |
Rear (exhaust) :
140 x 140 x 25 mm Riing RGB fan
(1400rpm, 28dBA)
Front (intake) :
140 x 140 x 25 mm Riing RGB fan
(1400rpm, 28dBA) x2 |
| Expansion Slots |
8+2 |
| Motherboards |
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX), 12” x 13”(E-ATX) |
| I/O Port |
USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1 |
| PSU |
Standard PS2 PSU (optional) |
| Fan Support |
Front:
3 x 120mm , 2 x 140mm
Top:
3 x 120mm , 3 x 140mm
Rear:
1 x 120mm, 1 x 140mm
Bottom:
2 x 120mm |
| Radiator Support |
Front:
1 x 360mm , 1 x 420mm
Top:
1 x 360mm , 1 x 420mm
Rear:
1 x 120mm, 1 x 140mm
Right:
1 x 360mm, 1 x 420mm
Bottom:
1 x 240mm |
| Clearance |
CPU cooler height limitation:
190mm
VGA length limitation:
310mm(With HDD Rack)
410mm(Without HDD Rack)
PSU length limitation:
220mm (Without Bottom Fan) |
