B550M-HVS SE

Mendukung Prosesor Desktop AMD AM4 Socket Ryzen™ 3000, 3000 G-Series, 4000 G-Series, 5000 dan 5000 G-Series*

Desain Daya 6 Fasa

Mendukung DDR4 4733+ (OC)

1 PCIe 4.0x16, 1 PCIe 3.0x1

Opsi Output Grafis: D-Sub, HDMI

Audio HD 7.1 CH (Kodek Audio Realtek ALC887/897)

4 SATA3, 1 Ultra M.2 (Gen3 x4 & SATA3)

6 USB 3.2 Gen1 (4 Belakang, 2 Depan), 6 USB 2.0 (2 Belakang, 4 Depan)

LAN Gigabit Realtek

Unique Feature

ASRock Super Alloy

• Premium 50A Power Choke

• Sapphire Black PCB

• High Density Glass Fabric PCB

ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)

ASRock Full Spike Protection (for all USB, Audio, LAN Ports)

ASRock Live Update & APP Shop

CPU

• Supports AMD AM4 Socket Ryzen™ 3000, 3000 G-Series, 4000 G-Series, 5000 and 5000 G-Series Desktop Processors*

• 6 Power Phase design

Chipset

• AMD PRO565

BIOS

• 128Mb AMI UEFI Legal BIOS with GUI support

• Supports "Plug and Play"

• ACPI 5.1 compliance wake up events

• Supports jumperfree

• SMBIOS 2.3 support

• CPU, CPU VDDCR_SOC, DRAM, VDDP Voltage Multi-adjustment

Graphics

• Integrated AMD Radeon™ Vega Series Graphics in Ryzen Series APU** Actual support may vary by CPU

• DirectX 12, Pixel Shader 5.0

• Shared memory default 2GB. Max Shared memory supports up to 16GB.*

• Dual graphics output: support D-Sub and HDMI ports by independent display controllers

• Supports HDMI 2.1 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz

• Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.1 Port (Compliant HDMI monitor is required)

• Supports HDR (High Dynamic Range) with HDMI 2.1

• Supports HDCP 2.3 with HDMI 2.1 Port* Picasso supports HDCP 2.2 with HDMI 2.0 Port

• Supports 4K Ultra HD (UHD) playback with HDMI 2.1 Port

• Supports Microsoft PlayReady

*The Max shared memory 16GB requires 32GB system memory installed.

Audio

• 7.1 CH HD Audio (Realtek ALC887/897 Audio Codec)

• Supports Surge Protection

LAN

• PCIE x1 Gigabit LAN 10/100/1000 Mb/s

• Realtek RTL8111H

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection

• Supports Energy Efficient Ethernet 802.3az

• Supports PXE

Slots

CPU:

• 1 x PCIe 4.0 x16 Slot (PCIE2), supports x16 mode*

Chipset:

• 1 x PCIe 3.0 x1 Slot (PCIE1)

*Supports NVMe SSD as boot disks

When using certain NVIDIA® RTX 4060 graphics cards on this motherboard, PCIE2 will run at PCIe 3.0 mode.

Storage

CPU:

• 1 x Ultra M.2 Socket (M2_1, Key M), supports type 2242/2260/2280 SATA3 6.0 Gb/s & PCIe Gen3x4 (32 Gb/s) modes*

Chipset:

• 4 x SATA3 6.0 Gb/s Connectors
