EZVIZ C6N 8MP SMART HOME CAMERA Image Sensor : 1/3" Progressive Scan CMOS Shutter Speed : Self-adaptive shutter Lens : 4mm@F1.6, ViewAngle: 110°(Diagonal), 92° (Horizontal), 51°(Vertical) Lens Mount : M12 Day & Night : IR-cut filter with auto-switching DNR : 3D DNR WDR : True WDR
PRODUCT DETAIL
EZVIZ C6N 8MP SMART HOME CAMERA SPESIFIKASI: CAMERA Image Sensor: 1/3" Progressive Scan CMOS Shutter Speed: Self-adaptive shutter Lens: 4mm@F1.6, ViewAngle: 110°(Diagonal), 92° (Horizontal), 51°(Vertical) Lens Mount: M12 Day & Night: IR-cut filter with auto-switching DNR: 3D DNR WDR: True WDR COMPRESSION Video Compression: H.264 / H.265 Video Bit Rate: Adaptive bit rate IMAGE Max. Resolution: 4K (3840 × 2160) Frame Rate: Self-adaptive during network transmission NETWORK Smart Alarm: -PIR Motion detection -AI-Powered Human Shape Detection -AI-Prowered Pet Shape Detection -Loud Noise Detection Wi-Fi Pairing: AP pairing / Bluetooth pairing Protocol: EZVIZ Cloud Proprietary Protocol Interface Protocol: EZVIZ Cloud Proprietary Protocol INTERFACE Storage: MicroSD card slot (max. 512 GB) Power: Type-C Wired Network: RJ45 × 1 (10 M / 100 M self-adaptive Ethernet port) Wi-Fi Standard: IEEE802.11a, 802.11b, 802.11g, 802.11n, Frequency Range: 2.4G: 2400~2483.5MHz 5G: 5170MHz-5250MHz Channel Bandwidth: 2.4G: Supports 20MHz 5GHz: Supports 80MHZ Security: WPA/WPA2, WPA-PSK/WPA2-PSK Transmission Rate: 11b 11Mbps, 11g 54Mbps, 11nHT20 MCS7, 11a 54Mbps, 11nHT20 MCS7 Output Power (EIRP): 19 dBm Antenna Gain: 1.9 dBi GENERAL Operating Conditions: -10°C to 45°C (14°F to 113 °F ) Humidity 95% or less (non-condensing) Power Supply: DC 5V / 2A Power Consumption: Max. 8 W IR Range: Max. 10 meters (32.81ft) Dimensions: 88 × 88 × 113 mm (3.46 × 3.46 × 4.45 inch) Packaging Dimensions: 103 × 103 × 168 mm (4.06 × 4.06 × 6.61 inch) Net Weight: 222 g (0.49 lb) IN THE BOX - C6N G1 Camera - Power Adapter - Power Cable - Drill Template - Mounting Plate - Screw Kit - Regulatory Information × 2 - Quick Start Guide CERTIFICATIONS Certifications CE / UL / WEEE / REACH / RoHS
